IPX800 V4 - Extension XTHL

€44.00
5 1
,
5/ 5
Tax included

The X-THL can measure temperature, humidity and the presence of light. It is possible to combine up to 14 X-THL to IPX800V4 & V5 and thus treat up to 12 additional analog data.

Color
Quantity

X-THL addon for IPX800 V4 & V5

The X-THL addon isn't a stand-alone device. Its features can only be accessed through the use of an IPX800 V4 & V5.

Technical features:

    • Addon port (Fieldbus, one pair + and -, category 6 network cable recommanded) for the IPX800 V4 & V5 (cable not supplied)
    • Temperature measurement from -40°F to +257°F (accuracy ± 33°F
    • Humidity level measurement (accuracy ± 3,5% at 77°F)
    • Measurement of light intensity (from 1 to 60 000 lux)
    • Recommanded power supply: from 3.3V to 5V continuous (not supplied) Max : 12V
    • Consumption : < 1 mA
    • Dimensions : 51 x 51 x 8 mm

2 years warranty

Made in France

X-THL-Noir
60 Items

Specific References

Download

Mode d'emploi X-THL

Mode d'emploi

Download (1.18M)
